Online Shopping Site for Buying MPPT Solar Inverters,mppt inverters, Mppt Solar Charge Controllers Lithium batteries & Solar panels Made in India Solar Products.Solar Inverter MPPT Controller Lithium Battery Panel solar inverter 4kva SPS Mppt Solar Hybrid Inverters.These are Mppt based solar hybrid inverters and are equipped with inBuilt MPPT Charge Controller.These are Pure sinewave inverters and are safe to all kind of loads.These inverters are based on switching MOSFETs.They have the Priority Solar Charging mode or otherwise called hybrid mode.These inverters are compatible with both Lithium and lead acid battery types. These inverters available in both aluminium and copper based transformers.Care should be taken while connecting the battery and Solar panels to this inverter.Always connect the battery first,then connect the solar panel.

The 3 Latest mppt charge controllers available are labeled as Red,Green and Yellow.The features of this charge controllers as below.Turn your normal/existing inverter into a solar inverter.Have a very long operational life and are incredibly reliable.When connected to a battery bank, its smart sensing feature will automatically identify the battery voltage 12/24/36/48/60/72V.You can turn off smart sensing manually using setting probe. Idle mode preserves battery life by preventing overcharging and battery water drain during extended periods of inactivity. Radio Frequency enabled remote with BLDC fan in Kerala. Four times efficient than ordinary fan.Available in black,brown,white and ivory colours . Advantages of BLDC fans 1. Traditional Ceiling fans run on AC motors. Yet, fans with BLDC technology use brushless DC engines that cut power consumption by 65%. 2. BLDC winding has thick copper cables to ensure a longer lifespan with low winding issues. These fans do not get overheated. 3. The carbon brushes are absent from the rotor and the stator of the BLDC fan. Hence, there is no hidden maintenance cost involved in the replacement of brushes. 4. BLDC fans maintain high torque to secure high-quality performance. 5. An induction motor has carbon bruises that create friction, which creates noise. A BLDC fan has zero friction, hence creating minimal noise. 6. BLDC motors comprise electronic control systems. That promotes fewer possibilities of collapse because of wear and tear but an induction motor fan has a mechanical commutation unit. Panka BLDC RF Fan Panka BLDC Wallmount Fan Panka BLDC Table Fan

LiFePo4 100Ah Lithium Iron Phosphate Battery Pack for Solar System.This will come inside a metal box with e grade prismatic cells,active balancer and BMS connected together. The combined product is ready to use and all cells will be balance and sorted. LiFePO4 12V 100AH Prismatic battery pack LiFePO4 12V 200AH Prismatic battery pack LiFePO4 24V 100AH Prismatic battery pack LiFePO4 24V 200AH Prismatic battery pack LiFePO4 48V 100AH Prismatic battery pack

How to setup solar off-grid hybrid system

Step 1: Assess Your Energy Needs

Calculate your daily energy consumption to determine system size requirements.

Step 2: Select the Location for Solar Panels

Choose a location with good sun exposure, free from shading obstacles.

Step 3:Determine the Size of the Solar Array:

Based on your energy needs and location, determine the number and size of solar panels you need. Solar panels are usually rated in watts (W) or kilowatts (kW).

Step 4:Solar Panel Installation:

Mount the solar panels securely on a frame or rack.Ensure they are tilted at the optimal angle to capture maximum sunlight Connect the solar panels in series or parallel to achieve the desired voltage and amperage.

Step 5:Install Charge Controller:

Connect a charge controller between the solar panels and the battery bank to regulate the charging process and prevent overcharging.

SPS Mppt charge controller autoselect YELLOW-40A-110C-4L

It has a 4-LINE display and will operate on 12-48V battery system with an ampere rating of 40A.It will support maximum solar panel voc of 110V.In 12V battery mode, it will support minimum solar panel voc of 15V and maximum solar panel voc of 55V.Maximum solar panel supported in 12v battery mode is 800W.In 24V battery mode, it will support minimum solar panel voc of 30V and maximum solar panel voc of 110V.Maximum solar panel supported in 24v battery mode is 1400W.In 36V battery mode, it will support minimum solar panel voc of 60V and maximum solar panel voc of 110V.Maximum solar panel supported in 36v battery mode is 1800W.In 48V battery mode, it will support minimum solar panel voc of 60V and maximum solar panel voc of 110V.Maximum solar panel supported in 48v battery mode is 2200W.

Sps mppt charge controller yellow-40

SPS SMART Mppt charge controller autoselect GREEN-80A

Sps smart mppt charge controller GREEN-80A

SPS Mppt charge controller autoselect GREEN-80A-190C-4L

It has a 4-LINE display and will operate on 12-72V battery system with an ampere rating of 80A.It will support maximum solar panel voc of 220V.In 12V battery mode, it will support minimum solar panel voc of 15V and maximum solar panel voc of 55V.Maximum solar panel supported in 12v battery mode is 1500W.In 24V battery mode, it will support minimum solar panel voc of 30V and maximum solar panel voc of 110V.Maximum solar panel supported in 24v battery mode is 2500W.In 36V battery mode, it will support minimum solar panel voc of 60V and maximum solar panel voc of 150V.Maximum solar panel supported in 36v battery mode is 3500W.In 48V battery mode, it will support minimum solar panel voc of 60V and maximum solar panel voc of 220V.Maximum solar panel supported in 48v battery mode is 4500W.In 72V battery mode, it will support minimum solar panel voc of 90V and maximum solar panel voc of 220V.Maximum solar panel supported in 72v battery mode is 5500W.

Sps mppt charge controller GREEN-80A

SPS Mppt charge controller autoselect RED-80A-280C-4L

It has a 4-LINE display and will operate on 48-144V battery system with an ampere rating of 80A. It will support maximum solar panel voc of 280V.In 48V battery mode, it will support minimum solar panel voc of 60V and maximum solar panel voc of 200V. Maximum solar panel supported in 48v battery mode is 4500W.In 72V battery mode, it will support minimum solar panel voc of 90V andmaximum solar panel voc of 200V.Maximum solar panel supported in 72v battery mode is 6500W.In96V battery mode, it will support minimum solar panel voc of 120V and maximum solar panel voc of 250V.Maximum solar panel supported in 96v battery mode is 7500W.In 120V battery mode,it will support minimum solar panel voc of 150V and maximum solar panel voc of 280V.Maximum solar panel supported in 120v battery mode is 9000W.In 144V battery mode, it will support minimum solar panel voc of 180V and maximum solar panel voc of 280V.Maximum solar panel supported in 144v battery mode is 11000W.

Sps mppt charge controller RED-80A

Step 6:Battery Bank Installation:

Choose the appropriate type of batteries (e.g., deep-cycle lead-acid, lithium-ion) and install them in a well-ventilated and secure location.Connect the batteries in a series or parallel configuration to achieve the desired voltage and capacity.

Step 7:Inverter Installation: mppt inverters

Install an inverter to convert the DC power from the battery bank into AC power that can be used in your home.Ensure the inverter is properly sized to handle your peak power demand.

Working of SPS Mppt Solar Hybrid Inverter 1.5KVA-12V-55VOC HS1500A. mppt inverters

Since this inverter is a 12V battery system model, it will switch to grid and solar as below.When the battery voltage reaches 14V it would disconnect your inverter from mains and entire load runs on battery & Solar. In evening, when solar power is low or battery voltage is below 11.5V, it will switch to mains.This solar mppt hybrid inverter is capable to load 1.1KW of surge load and able to run 500W load continuously.Minimum VOC of the panel supported is 20V and Maximim VOC supported is 55V.Maximum solar panels supported is 800W.The ampere rating of mppt is 40A.

Solar Hybrid Inverter 1.5KVA-12V-55VOC

Working of SPS Mppt Solar Hybrid Inverter 2KVA-24V-55VOC HS2000A. mppt inverters

Since this inverter is a 24V battery system model, it will switch to grid and solar as below.When the battery voltage reaches 28V it would disconnect your inverter from mains and entire load runs on battery & Solar. In evening, when solar power is low or battery voltage is below 23V, it will switch to mains.This solar mppt hybrid inverter is capable to load 1.5KW of surge load and able to run 1000W load continuously.Minimum VOC of the panel supported is 20V and Maximim VOC supported is 55V.Maximum solar panels supported is 1600W.The ampere rating of mppt is 40A.

Solar Hybrid Inverter 2KVA-24V-55VOC

Working of SPS Mppt Solar Hybrid Inverter 3KVA-24V-110VOC HS3000A. mppt inverters

Since this inverter is a 24V battery system model, it will switch to grid and solar as below.When the battery voltage reaches 28V it would disconnect your inverter from mains and entire load runs on battery & Solar. In evening, when solar power is low or battery voltage is below 23V, it will switch to mains.This solar mppt hybrid inverter is capable to load 2.2KW of surge load and able to run 1000W load continuously.Minimum VOC of the panel supported is 40V and Maximim VOC supported is 110V.Maximum solar panels supported is 1600W.The ampere rating of mppt is 40A.

Solar Hybrid Inverter 3KVA-24V-100VOC

Working of SPS Mppt Solar Hybrid Inverter 4KVA-36V-110VOC HS4000A.mppt inverters

Since this inverter is a 36V battery system model, it will switch to grid and solar as below.When the battery voltage reaches 42V it would disconnect your inverter from mains and entire load runs on battery & Solar. In evening, when solar power is low or battery voltage is below 34.5V, it will switch to mains.This solar mppt hybrid inverter is capable to load 3KW of surge load and able to run 1500W load continuously.Minimum VOC of the panel supported is 40V and Maximim VOC supported is 110V.Maximum solar panels supported is 2400W.The ampere rating of mppt is 40A.

Working of SPS Mppt Solar Hybrid Inverter 4KVA-48V-110VOC HS4000A.mppt inverters

Since this inverter is a 48V battery system model, it will switch to grid and solar as below.When the battery voltage reaches 56V it would disconnect your inverter from mains and entire load runs on battery & Solar. In evening, when solar power is low or battery voltage is below 46V, it will switch to mains.This solar mppt hybrid inverter is capable to load 3KW of surge load and able to run 2000W load continuously.Minimum VOC of the panel supported is 40V and Maximim VOC supported is 110V.Maximum solar panels supported is 3200W.The ampere rating of mppt is 40A.

Solar Hybrid Inverter 4KVA-48V-100VOC

Working of SPS Mppt Solar Hybrid Inverter 4KVA-24V-110VOC HS4000A.mppt inverters

Since this inverter is a 24V battery system model, it will switch to grid and solar as below.When the battery voltage reaches 28V it would disconnect your inverter from mains and entire load runs on battery & Solar. In evening, when solar power is low or battery voltage is below 23V, it will switch to mains.This solar mppt hybrid inverter is capable to load 3KW of surge load and able to run 1000W load continuously.Minimum VOC of the panel supported is 40V and Maximim VOC supported is 110V.Maximum solar panels supported is 2400W.The ampere rating of mppt is 40A.

Solar Hybrid Inverter 4KVA-24V-100VOC

Working of SPS Mppt Solar Hybrid Inverter 5KVA-48V-150VOC HS5000A.mppt inverters

Since this inverter is a 48V battery system model, it will switch to grid and solar as below.When the battery voltage reaches 56V it would disconnect your inverter from mains and entire load runs on battery & Solar. In evening, when solar power is low or battery voltage is below 46V, it will switch to mains.This solar mppt hybrid inverter is capable to load 3.75KW of surge load and able to run 2000W load continuously.Minimum VOC of the panel supported is 40V and Maximim VOC supported is 110V.Maximum solar panels supported is 3200W.The ampere rating of mppt is 40A.

Solar Hybrid Inverter 5KVA-48V-100VOC

SPS Mppt Solar Hybrid Inverters.mppt inverters

These are Mppt based solar hybrid inverters and are equipped with inBuilt MPPT Charge Controller. They have the Priority Solar Charging mode or otherwise called hybrid mode. In Hybrid mode, they will enable the inverter to charge the battery by sensing the solar light at day time and charge from grid when the solar light is absent. So grid energy and solar energy will be utilised based on the light availability.Hence the name hybrid.If this Solar Mode/Hybrid Mode switch is OFF ,the Inverter will be in Hybrid mode.In this mode, inverter will charge from both solar and grid.If Solar present, it will charge the battery from Solar. If solar light is not detected,then it will charge from Grid/mains.If Solar Mode/Hybrid Mode switch is ON , then the Inverter will be in Solar mode.Inverter will charge the battery from Solar Only. These inverters are compactibale with both Lithium and lead acid battery types. These inverters available in both aluminium and copper based transformers. Care should be taken while connecting the battery and Solar panels to this inverter. Always connect the battery first, then connect the solar panel.

Solar Hybrid Inverter 7.5KVA 72V Solar Hybrid Inverter 7.5KVA 48V Solar PCU 7.5KVA Solar Hybrid Inverter 4KVA 36V Solar Hybrid Inverter 5kva 36v sps mppt white 80 lifepo4 prismatic cell 48v 200ah
